产品名称：MB8-220G/220E/300/300D - 给袋式包装机
- 详细介绍
| 型号 | MB8-220G | MB8-220E | MB8-300 | MB8-300D |
| 包装袋规格 | W:70-220mm L:100-300mm | W:170-300mm L:200-500mm | ||
|
袋子类型 Bag type |
铝箔袋、尼龙袋、纸袋等四边封复合袋(适用于自立袋，拉链袋，异型袋等) Aluminum foil bags, nylon bags, paper bags and other four-side sealed composite bags(Suitable for doypack, zipper bags, special-shaped bags, etc.) |
|||
|
充填范围 Filling range |
10-1000g | 500-3000g | ||
| 包装速度 | 35-70包/分钟 (bags/min) | 30-45包/分钟 (bags/min) | 15-40包/分钟 (bags/min) | 15-35包/分钟 (bags/min) |
|
主机重量 Host weight |
1500kg | 1800kg | ||
| 主机功率 | 4KW | |||
|
驱动电源 Drive power |
三相五线 380V 50HZ Three-phase five-wire 380V 50HZ |
|||
|
外形尺寸 Dimensions |
1850×1550×1580 | 2650×1560×1710 | 2200×1900×1600 | 2950×1700×1810 |
|
耗气量 Air consumption |
≤0.5m³/min (压缩空气由用户自行提供) compressed air is provided by the user |
|||
样品:
